GPON FTTH ONU Equipment WIFI 3FE 1USB 1POTS 1GE XPON ONT Router

ZIKUN GPON ONU 1GE 3FE 1USB 1POTS WiFi 802.11AC ZC-520 XPON ONT





Product Description





ZC-520 is based on mature and stable, cost-effective EPON/GPON technology,
high reliability, easy management, configuration flexibility and good
quality of service (QoS) guarantees to meet the technical performance of
IEEE802.3ah and ITU-TG.984.x , China Telecom EPON/GPON equipment technical
requirements and other specifications.




ZC-520 GPON 1GE+3FE+1USB+1POTS+WIFI ONU meets telecom operators FTTO
(office), FTTD (Desk) ,FTTH(Home) broadband speed, SOHO broadband access,
video surveillance and other requirements to design an GPON Gigabit Ethernet
products.







GPON 1GE+3FE+1USB+1POTS+WiFi





GPON FTTH ONU Equipment WIFI 3FE 1USB 1POTS 1GE XPON ONT Router 0



Key Features



GPON/ EPON mode adaptive.
Plug and play, features auto-detecting, auto-configuration, and auto
firmware upgrade, etc.
Integrated OMCI remote configuration and maintenance function.
Support rich QinQ VLAN functions and IGMP Snooping multicast features.
Fully compatibility with OLT based on Broadcom/PMC/Cortina chipset.
Support 802.11n WiFi(2T2R) function.
Support NAT, Firewall function.
Support IPv4 and IPv6 dual stack.
Integrated line testing compliant with GR-909 on POTS.






Specifications



GPON FTTH ONU Equipment WIFI 3FE 1USB 1POTS 1GE XPON ONT Router 1



Technical item 1GE+3FE+1POTS+WiFi
PON
1 G/EPON port(EPON PX20+ and GPON Class B+)

Receiving sensitivity: ≤-28dBm

Transmitting optical power: 0~+4dBm

Transmission distance: 20KM

Wavelength Tx1310nm,Rx 1490nm
Optical SC/UPC connector
LAN
Auto-adaptive 10 Mbit/s, 100 Mbit/s or 1000 Mbit/s,MAC address learning

POTS . SIP/ H.248
. Call waiting, Inconditional Call Forward, Call Forward if Busy,Call
Forward if no reply and Three-party calls.
. G.711A/U, G.729 and G.722 encoding/decoding
. T.30/T.38/G.711 fax mode
. SDP protocol (RFC 2327 and RFC 4566)
. DTMF
WiFi
. IEEE 802.11 b/g/n (2.4G)
. 2 × 2 MIMO
. Antenna gain: 5 d Bi ,double external antenna
. Air interface rate:300 Mbit/s
. WMM
. Multiple SSIDs
. WPS

USB port

. USB2.0 ,USB backup
. FTP-based network storage
. File/Print sharing based on SAMBA
. UPnP








Order Information



Product model Product specification Chipset SDRAM Memory
ZC-520GPON 1GE+3FE+1POTS+WIFI+1USB Hisilicon 64MB
