SC Simplex Fiber Optic Adapter With Flange

SC Simplex Fiber Optic Adapter With Flange
The fibre optic adapters are available in single mode and multimode variants.
The single mode adapters feature ceramic sleeves and the multimode have
phosphor bronze sleeves. The adapter housings are available in different
colours and have fixing flanges and metal clips. Protective caps the same
colour as housing are provided for each end of the adapter.

High size precision.
Good repeatability.
Good changeability.
Good temperature stabilization.
High wearable

Product Name SC Fiber Adapter
Type SC/APC SM Simplex
Material ABS
Color Green or OEM
Insertion Loss ≤0.2db
Return Loss ≥50db
Packing 50 Pcs/BlisterBox
Certification los9001:2008

Applications
CATV System
Telecommunications
Optical Networks
Testing/Measurement Instruments Fiber Tothe Home

We offer a variety of fiber optic adapters. These adapters are used to connect
and align two fiber optic connectors. They bridge the gap between cable-to-
cable fiber optic connections and are sometimes referred to as mating sleeves
or hybrid adapters. They come in different connection forms, which can be
single, dual, or sometimes quad. This is commonly known as single-mode or
multimode fiber optic cable connections.
